Image Sensor:

5MP CMOS Image Sensor

Effective Pixels:

2560 (H) × 1944 (V)

Shutter Time:

1/25(1/30) s to 1/50,000 s

Lens Mount:

M12

Adjustment Range:

Pan: 0° to 360°; Tilt:0° to 180°; Rotate: 0° to 360°

Day& Night:

IR cut filter with auto switch

Video Frame Rate:

2560 × 1944 @ 20fps

HD Video Output:

1 Analog HD output

Synchronization:

Internal Synchronization

D/N Mode:

Auto / Color / B/W

Auto White Balance:

Auto/MWB

BLC:

Support

Language:

English/Chinese

Operating Conditions:

-40 °C - 60 °C (-40 °F - 140 °F)
Humidity 90% or less (non-condensing)

Power Supply:

12 VDC±25%

Weather Proof:

IP67

IR Range:

Up to 20m

Communication :

Up the coax
Protocol: HIKVISION-C(Coaxitron)

Dimension:

58 mm × 61 mm × 163 mm (2.28" × 2.40" × 6.42")

Weight:

Approx. 350 g (0.77 lb.)
